Dormer M5 x 0.8 HSS Plug Hand Tap E559

Introduction

Straight flute ECON hand tap, chamfer form C, 2-3xP plug lead, ISO-Metric Coarse thread M5 x 0.80mm pitch, 6H class of fit, ISO 529 standard, 5mm shank and 4mm square drive, HSS bright finish for 1.5XD through or blind hole threading.

Brand :Dormer

Manufacturer Part Number :E559M5NO3

Additional Information :Bright finish. Prevents work piece material from sticking to the cutting edge. Simple, strong design in high-quality HSS. Cost Effective solution for general usage. Straight flute. Designed for efficient threading of through and blind holes.

Pitch (mm) :0.8

Thread Length (mm) :16

Overall Length (mm) :58

Number of Flutes :3

Coating/Finish :Uncoated
